Guide To The Intermittent Bonded Ribbon Production Line
An intermittent bonded ribbon production line connects fiber subunits at set intervals. This maintains fibers in an organized arrangement for mass-fusion splicing while letting the ribbon roll or fold into a compact cable shape. Flexible ribbon cable production is supported by this design while maintaining efficient fiber handling.
In some processes, bonding material is applied while the subunit coating is still uncured. Diffusion can occur across the shared interface before the materials cure together. Prysmian’s FlexRibbon technology provides one commercial example, and the company dates its original design to 2018. These methods illustrate how optical fiber ribbon manufacturing and fiber optic bonding operate together.
Fiber Draw Tower Fiber Coloring Machine Fiber Draw Tower
What Is An Intermittent Bonded Fiber Ribbon?
An intermittent bonded fiber ribbon organizes optical fibers into small subunits. The subunits stay organized for splicing while remaining able to change shape to fit inside a cable.
The Arrangement Of Fiber Subunits And Intermittent Bonds
Each adjacent pair or group of fibers is held together by a coating. These optical fiber subunits connect to neighboring subunits at separated bond points rather than along their full length. A 12-fiber design may use six two-fiber subunits. The configurations range from 4 to 36 fibers, and bond spacing ranges from 10 to 1,000 millimeters.
Intermittent Bonded Ribbon Production Line
Differences Between Rollable Ribbons And Conventional Flat Ribbons
A conventional flat ribbon keeps its fibers in a single fixed plane. A rollable fiber ribbon can curl between bonds while retaining fiber alignment for mass-fusion splicing. Bending and folding are supported by the small bonding points used in Prysmian’s FlexRibbon.
Why Flexible Ribbons Support Compact, High-Density Cables
Ribbon flexibility limits the space it occupies inside a high-density fiber cable. This enables cable designers to fit more fibers into a compact structure while preserving an organized fiber layout.
Process And Equipment For An Intermittent Bonded Ribbon Production Line
Throughout an intermittent bonded ribbon production process, optical fibers are arranged side by side along the ribbon’s length. Subunits are created when a first material coats groups containing two or more fibers. Neighboring subunits are joined at spaced points with a second material, leaving flexible sections between bonds.
Arrange Adjacent Optical Fibers Into Subunits
The planned ribbon layout determines how fibers are positioned next to one another. Each selected group becomes a subunit when the first coating material surrounds and holds its fibers together.
Deposit Subunit Coating And Intermittent Bonding Material
Fiber ribbon coating creates the subunits. A discrete coating applicator deposits bonding material between neighboring subunits at intervals rather than along their entire length.
Create Diffusion Zones Through Wet-On-Wet Application
Wet-on-wet bonding involves depositing the bonding material before the subunit coating has cured. A diffusion zone develops as the materials intermix through their shared interface.
Cure The Subunit Coating And Bonds Together
A single curing step sets both the subunit coating and the intermittent bonds. Optical fiber ribbon equipment performs these operations, although a complete equipment list, line speed, and production capacity are not specified.
| Process Stage | Material Or Action | Intended Purpose |
|---|---|---|
| Optical fiber arrangement | Arrange fibers next to one another | Set the ribbon layout |
| Formation of subunits | Apply the first coating material around fiber groups | Keep groups of two or more fibers together as subunits |
| Intermittent bonding | Deposit the second material between neighboring subunits | Connect subunits at separated bond points |
| Wet-on-wet interface | Apply bonds before the subunit coating cures | Enable formation of a diffusion zone between the materials |
| Joint curing step | Cure coating and bonds in one step | Cure the assembled ribbon structure |
Main Production Line Stages And Process Controls
Fiber ribbon production stages take place in a specific sequence. The sequence involves organizing fibers into subunits, applying a subunit coating, placing intermittent bonds between adjacent subunits, and curing the coating and bonds together. The ribbon design must guide both optical fiber coating application and positioning of the bonds.
Gaps of 5 to 100 micrometers between subunits are described in example designs. A range of 10 to 1,000 millimeters is specified for intermittent bond spacing in example designs. Some bond deposits take a diamond-like shape, narrowing at the ends and widening in the center. The disclosed examples should not be treated as fixed settings that apply to every line.
The selected materials, bond layout, and curing method determine ribbon manufacturing process control. Because the source material provides no line speeds, curing temperatures, or inspection intervals, avoid assuming any values for them.
Ribbon Flexibility, Bond Design, And Materials
Material selection and bond layout govern how the ribbon behaves during cable making and splicing. Coatings shield each fiber while permitting the subunits to flex as intended.
Select Compatible Coating And Bonding Materials
Subunit coatings and ribbon bonding materials have different functions, so their formulas need not be identical. Resins that mix or remain at least partly soluble can produce a gradual interface. Lower coating viscosity may also promote intermixing.
This interface forms a diffusion zone in which properties change gradually. Differences in colour, stiffness, surface friction, tear strength, or stretch may occur within this zone. The disclosed thickness range is 2 to 50 micrometers, while 5 to 15 micrometers is given as a narrower range.
Control Bond Placement, Spacing, And Geometry
Bond spacing determines where fiber subunits stay connected and where they can move freely. Intermittent bond geometry provides unbonded spans between bond points. Intersecting convex and concave curves create the saddle shape used on some bond surfaces.
Maintain Fiber Organization While Balancing Ribbon Flexibility
Unbonded spans allow the ribbon to shift from a flat layout into a rolled, curled, or folded shape. A flexible fiber ribbon design bends during cable installation while keeping fibers organized for splicing.
Quality Checks For Consistent Ribbon Production
Reliable fiber ribbon quality checks measure defined features rather than relying on assumed pass limits. Design factors named in the patent include the spacing of bonds, subunit gaps, diffusion-zone thickness, and bond shape. However, it does not specify inspection methods or acceptance limits.
Check Bond Continuity And Subunit Alignment
Check that intermittent bonds join adjacent subunits at planned locations and leave unbonded lengths between connections. Review subunit alignment and gaps because movement can affect ribbon shape and bond geometry.
Assess Ribbon Flexibility And Rollability
Assess ribbon rollability by examining how the ribbon bends and gathers without changing fiber order. Compare bond spacing and flexibility across the overall ribbon design. These comparisons are design checks, not universal production tolerances.
Confirm Fiber Identification And Ribbon Configuration
Use fiber color coding to check the position of each fiber. A common 12-color sequence is blue, orange, green, brown, slate, white, red, black, yellow, violet, rose, and aqua. The color sequence may repeat when a ribbon has more than 12 fibers.
Applications, Cable Integration, And Splicing Benefits
Intermittently bonded ribbons can roll inside a cable, enabling more fibers to fit into a compact design. Prysmian says FlexRibbon supports high-density ribbon cable designs, smaller diameters, and improved fiber duct utilization.
Support High-Density Cable Designs And Duct Utilization
For indoor, outdoor, and indoor/outdoor applications, Prysmian provides FusionLink and MassLink with FlexRibbon. Dry water blocking is used in FusionLink, which comes with either 250 μm or 200 μm ribbon. EcoSpan aerial cable supports spans of up to 300 feet under NESC Heavy loading conditions. FlexDrop is a small-diameter outdoor option that accommodates up to two 12-fiber ribbons.
Support Mass-Fusion Splicing And Quicker Deployment
Mass-fusion splicing connects several ribbon fibers in a single operation, often 12 at once. On compatible ribbon routes, this method can reduce splice time. For loose-tube cable connections, technicians separate the ribbon fibers and splice them one by one using a single-fiber splicer.
Consider Indoor, Outdoor, Access, And Broadband Uses
Ribbon cable is used in point-to-point networks, indoor FTTH systems, MTP wiring-box links, and urban trunk routes. Choosing indoor and outdoor fiber cable to suit the route aligns its construction with building, aerial, and underground requirements.
Final Conclusions
An intermittent bonded ribbon line guide covers fiber layout, bond placement, curing, and inspection. The result is a flexible optical fiber ribbon that remains organized during handling yet can roll or fold into compact cable designs.
The process involves depositing bonds while the subunit coating is still uncured. Before they cure together, the materials develop a diffusion zone. Careful control throughout the process supports reliable fiber cable manufacturing.
Mass-fusion ribbon splicing is also supported by flexible ribbons, helping crews splice many fibers in one operation. FlexRibbon is described by Prysmian as suitable for various cable designs, including compact configurations with up to 6,912 fibers.
For manufacturers and network planners, the priority is to balance fiber alignment, bond strength, and rollability. This balance may make cable packaging easier while ensuring ribbons remain prepared for efficient installation and splicing.
